CWFL-6000ENS04 Industrial Water Chiller for Fiber Laser 6000W

the cwfl-6000ens04 is an industrial water chiller designed for fiber laser cooling applications. by cooling the laser device, it keeps laser output power stable and ensures light beam quality, improving both the working life and cutting accuracy of the laser device. equipped with dual temp control, overcurrent protection for the compressor, and comprehensive alarm systems, it delivers reliable, energy-efficient cooling performance for 6000w-class fiber laser systems.

spec:

• machine model: cwfl-6000ens04
• voltage: ac 3p 380v
• frequency: 50hz
• current: 2.1-18.8a
• max power consumption: 7.4 kw
• heater power: 1kw + 1.8kw
• precision: ±1°c
• reducer: capillary
• pump power: 1.1 kw
• tank capacity: 40 l
• inlet and outlet: rp1/2" + rp1"
• max pump pressure: 61.5 m
• rated flow: 1.5 l/min + >50 l/min
• net weight: 108 kg
• gross weight: 122 kg
• dimension: 76 x 56 x 102 cm (l x w x h)
• package dimension: 78 x 65 x 117 cm (l x w x h)

structure:

• capillary-based temperature reducer for precise cooling control
• dual temp control system for stable operating temperature
• built-in pump with 61.5m max pressure for reliable water circulation
• expanded tank design with 40l capacity for higher cooling loads

use:

• application: cooling fiber laser devices to maintain stable output power and consistent beam quality
• compatibility: suitable for 6000w-class fiber laser resonators
• benefit: improves working life and cutting accuracy of the connected laser device

quality:

• energy saving design for efficient power consumption
• overcurrent protection for compressor to prevent damage
• over temp alarm and flow alarm for operational safety
• dual temp control for consistent cooling precision

included:

• 1 x cwfl-6000ens04 industrial water chiller
